Modèn konsepsyon aliminyòm ankadreman

Name: Aliminyòm pwofil manifakti
Uploaded: 2023-09-14T01:15:30+08:00
Description: Etabli an 1993, Guang Yuan ansyen elèv se yon manifakti pwofesyonèl pwofil aliminyòm. Guang Yuan gen eksperyans 28

$93-115 /Square Meter

Kalite peman:	T/T
Incoterm:	FOB,CIF,EXW
Min. Lòd:	500 Square Meter
Transpòtasyon:	Ocean,Land,Air,Express,Others
Port:	SHEN ZHEN ,GUANGZHOU ,FOSHAN

Frame material:

Aluminum Alloy

Kontakte kounye a

Deskripsyon Product

Atribi pwodwi yo

Anbalaj & akouchman

Deskripsyon Product

Atribi pwodwi yo

Modèl Pa gen.: W08

Brand: Guang Yuan

After-sales Service: Online Technical Support, Other

Engineering Solution Capability: Graphic Design, 3d Model Design, Total Solution For Projects, Others

Application Scenario: Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Supermarket, Warehouse, Workshop, Courtyard, Farmhouse, Other, Kitchen, Outdoor, Basement

Design Style: Modern, Traditional, Chinese

Place Of Origin: China

Anbalaj & akouchman

Vann Inite	:	Square Meter
Kalite pake	:	Kim epe, papye kraft, ka an bwa, sipò fè
Egzanp foto	:

The file is encrypted. Please fill in the following information to continue accessing it

Aliminyòm pwofil manifakti

Fenèt aliminyòm ak pòt



Deskripsyon Product

Etabli an 1993, Guang Yuan ansyen elèv se yon manifakti pwofesyonèl pwofil aliminyòm. Guang Yuan gen eksperyans 28 ane nan manifakti Des èkstruzyon aliminyòm pou achitekti aliminyòm Des mi rido, glisman pòt yo, ak balistrad vè, pòt aliminyòm ak fenèt sistèm lavabo chalè, Des endistriyèl aliminyòm , kabinè kwizin, pandri mèb aliminyòm, elatriye.

Avèk plis pase 20 machin èkstruzyon aliminyòm , anodize ak liy pwodiksyon elèktroforèz, liy pwodiksyon kouch poud, liy pwodiksyon an bwa transfè chalè, ak liy pwodiksyon kouch PVDF, kapasite pwodiksyon nou yo te rive 150,000 tòn pwofil aliminyòm nan yon ane.

Nou te kòmanse biznis ekspòtasyon nou an depi 1998 ak pwodwi nou yo te ekspòte nan sid ès Azi, Mwayen Oryan, East Ewòp, Afrik ak Amerik di Sid, tankou Vyetnam, Thailand, Malezi, UAE, Arabi Saoudit, Irak, pèp Izrayèl la, Larisi, Polòy , Ikrèn, Gana, Tanzani, Lafrik di sid, Mali, Benen, Chili, Bolivi, Irigwe, Perou ak Meksik, elatriye.

Pòt aliminyòm artikulé refere a yon pòt ak gon (gon) enstale sou bò pòt la, louvri anndan (kite anndan, dwa anndan) oswa deyò (kite deyò, dwa deyò). Li konsiste de kouvèti pòt, charnyèr, fèy pòt, fèmen ak sou sa.

Lè dekorasyon yon twalèt, moun anjeneral chwazi aliminyòm pòt artikulé. Se pou nou fè yon gade nan karakteristik sa yo nan pòt aranjman aliminyòm.

Karakteristik nan premye nan pòt la artikulé aliminyòm se sante ak pwoteksyon anviwònman an, paske penti lou pa itilize, li pa pral lakòz polisyon nan anviwònman an lakay ou. Pòt la aliminyòm artikulé pa pral defòme oswa dekolore anba limyè solèy la dirèk, ak pèfòmans lan se byen ki estab.

Karakteristik nan dezyèm nan pòt la aliminyòm artikulé se senplisite li yo ak légèreté. Liy yo sou tout fasad la yo trè mou, ki bay sal la ap viv yon santiman cho san yo pa twò grav. Li te tou te lajman fè lwanj pou aparans li yo.

Karakteristik nan twazyèm nan pòt la aliminyòm artikulé se pri abòdab li yo. Li pa sèvi ak tout-wo klas bwa tankou pòt la orijinal an bwa, ki lakòz pri a vag ak vin yon liksye.

Avantaj ki genyen nan pòt la aliminyòm artikulé se ke pèfòmans nan poze sele se yon bon bagay, se efè a izolasyon son garanti, pèmeyabilite ki an jeneral se fò, ak espas la se bon ak nòb. Men, li tou pote feblès nan sikilasyon espas ensifizan. Nan sans de sitiyasyon sa a, vantilasyon an ki ka itilize lè fèmen fenèt la pa afekte izolasyon son an, epi asire echanj lè andedan kay la epi deyò. Ka vantilasyon an dwe enstale nan yon ti espas ant fenèt la ak liy lan fenèt.

Product Name	Aluminium Windows and Doors
Manufacturing Standard	AS2047
Quality Certificate	ISO 9001:2015, ISO 14001:2015, CQM Certification, SGS
Aluminium Profiles	6063-T5 high quality thermal/non-thermal break aluminium profiles
Profiles Thickness	1.4mm for windows, 2.0mm for doors
Surface Treatment	Anodizing, electrophoresis, powder coating, fluorocarbon, and wooden color
Color	Silver, champagne, bronze, white, charcoal, black, brown, grey and wooden colors
Glazing Type	tempered glazing, tinted glazing, frosted glazing, reflective glazing, laminated glazing and LOW-E glazing
Glazing Thickness	Single tempered glazing: 5mm, 6mm, 8mm, 10mm and 12mm
	Double tempered glazing: 4+12A+4mm, 5+9A+5mm, 5+12A+5mm, 5+15A+5mm, 5+19A+5mm and 6+12A+6mm
Mesh	Stainless steel security mesh, diamond mesh, aluminium security mesh, and fiberglass flyscreen
	Retractable screen, fixed screen and sliding screen
Sealing	Chinese famous brand silicone and EPDM strips
Hardware	KINLONG, HOPPE, HOPO, SIEGENIA AUBI, CMECH
Architrave	Depending on the customer’s requirements
Guarantee	10 years to 20 years
Application	Residential houses, commercial buildings, luxurious villas, modular houses, prefab houses and steel structure houses
MOQ	1 set
Packing Details	EPE foam packing and wooden crate packing
Payment Term	1) T/T: 30% of total value as deposit by T/T within 3 days to confirm the order, and the balance to be paid by T/T before loading the container.
	2) L/C: 30% of total value as deposit to be paid by T/T within 3 days to confirm the order, and the balance to be paid by L/C at sight after loading the container.
	3) Big order: Pay 30% of total value as deposit by T/T within 3 day to confirm the order, and the balance to be paid by T/T after delivery against the copy of B/L.
STRUCTURAL PARAMETERS
Profile Thickness	Frame Depth			Sash Width
2.0mm	138mm			90mm
PERFORMANCE PARAMETERS
Heat Insulation(m2·K)	Sound Insulation(DB)	Water Tightness(PA)	Air Tightness	Wind Load(KPa)
4W	45DB	700PA	4.5≤92>3.0	3.5≤P3>4.0
Level 4	Level 4	Level 6	Level 8	Level 8
FAQ
1. Q: Where is your factory located? A: Our factory is located in Foshan City, China, it takes about an hour from Guangzhou Baiyun Airport to our factory, about an hour from Canton Fair. 2. Q: What is your minimum order quantity? A: Our minimum order quantity is 1 set.
3. Q: What are the colors available? A: Our colors are available for our factory colors stock, and can be customized as per customer’s color sample.
4. Q: What is your lead time for production? A: We can complete the order around 20-45 days. because aluminium extrusion is by our factory, we can control lead time
5. Q: Did you export aluminum windows to overseas countries? A: We have exported our profiles to South East Asia, Middle East, East Europe, South America and Africa, etc.
